Bluefin 21.5'' BrightSign Touch

Bluefin 21.5'' BrightSign Touch

Bluefin combines the beautiful touch tablet with the power of BrightSign.

  • 21.5" LCD Touch Display
  • 1920x1080 Resolution
  • BrightSign Built-In player
  • Finished Housing
  • SKU:20-3008-1101
  • GTIN/EAN:
  • MPN:20-3008-1101

You need to login to view the price.

Add To Favorite
View full details

The POWER of BLUEFIN / BRIGHTSIGN

The robust BrightSign digital signage ecosystem integrated with industrial quality LCD screens.
Create complex and engaging presentations with layers of video, images, audio, HTML widgets and more.
Update new playlists and deploy them to a fleet of players from one location.
Connect with external devices through GPIO and Serial to take experiences beyond the screen to control house lighting, RFID accessories and more.

Housings designed to maximize ease-of-use and installation, and built tougher than your average TV. The all-metal, simple construction mounts quickly and conveniently.

Display Input / Output Power Housing / Mounting
  • 21.5'' LCD Screen
  • Native Resolution: 1920x1080
  • Max Brightness: 300 nits
  • Viewing Angle: 89/89/89/89
  • Contrast: 3000CR
  • Optional: Capacitive Touch
  • Storage: Micro-SD
  • 1x USB 2.0
  • Phoenix GPIO (4-pin Bi-Directional)
  • 3.5mm RS232 Serial
  • RJ45 Ethernet
  • Optional: Wi-Fi / Bluetooth
  • 2x Stereo 3W Speakers
  • 3.5mm Audio Out (Digital and Analog)
  • Adapter Style: Micro Molex
  • Adapter Output: 12V 3A
  • Adapter SKU: 20-0150-0641
  • Optional Power over Ethernet
    PoE 802.3bt (60W)
  • Overall Dimensions: 20.6'' x 12.5'' x 2.0''
  • Weight: 12.5 lbs (5.65kg)
  • Mounting: VESA 100x100mm M4x8mm
Display
Touch technology
Capacitive Touch
Display brightness
300
Display resolution
1920 x 1080
Display diagonal
21.5"
Software
Platform
BrightSign
Other features
Maximum resolution
1920 x 1080
Manufacturer
BlueFin
