LG LAEC015-GN2 136" All-In-One display

LG LAEC015-GN2 136" All-In-One display

136" LED, 1920 x 1080, 500 nit, 3000:1, RMS 18W, Embedded System Controller, webOS

  • Pixel Pitch: 1.56 mm
  • Screen Size: 136" (Full HD)
  • Brightness: 500 nit
  • Embedded System Controller
  • Built-in Speaker
  • Dedicated Accessories : Wall Mount, Motorized Stand (Optional)
  • SKU:195174047361
  • GTIN/EAN:195174047361
  • MPN:LAEC015-GN2

You need to login to view the price.

Add To Favorite
View full details

LG LAEC015-GN2. Product design: Digital signage flat panel. Display diagonal: 3.45 m (136"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 500 cd/m², HD type: Full HD. Wi-Fi. Operating system installed: Web OS. Product colour: Black

All-in-One LED Screen with Built-in Speaker

The LAEC series is a 136-inch large screen which is offered as an all-in-one package including an embedded controller and built-in speaker. Eliminating the prejudice that LED displays are difficult and complex to install, it doesn't require controller connections or module configuration. After a simple installation process, all you need to do is to turn on the screen with a remote control like home TV.

High Performance with webOS

Built-in Quad Core SoC (System on Chip) can execute several tasks at once for providing smooth content playback. Also, LG webOS Smart Platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools* such as SDK (Software Development Kit), SCAP, sample applications.

LG’s Wireless Screen Sharing Solution, LG One:Quick Share

LG One:Quick Share is a wireless screen sharing solution available through the LAEC series, USB transmission unit, and its app. You can simply share personal PC screen to the display with it's USB dongle button and embedded Wi-Fi and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode helps you to display the agenda, note before the meeting starts.

Easy Installation

The installation process of the All-in-One Smart series is very simple. After securing two cabinets which are included in the flight kit, attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.

Quick Maintenance

In case of failure related to the LED module or the system board, it can be serviced from the front. The LED module can be simply detached by the provided magnetic tool and replaced quickly without cabling.

Dedicated Installation Accessories

The product is offered with the flight case which includes every necessary component including the landscape wall mount and tools for installation. The motorized stand is provided as an option, so that you can easily place it depending on your installation sites. With this stand, you can adjust a height of the screen including stand from 2.0 m to 2.5 m.

Compatible with AV Control Systems

The LAEC series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.

Real-Time LG ConnectedCare

Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.

Magic Remote for Easy of Use

With the LG Magic Remote, you can select and run the menu of the signage just like using a mouse and its cursor can be used as a laser pointer. In addition, through the newly added 'FREEZE' button on the remote control, users can temporarily freeze the screen while switching contents on the PC, so that users are able to have uninterrupted meetings without exposing its switching process.

Display
Native refresh rate
2880 Hz
Rated lifetime
100000 h
Pixel pitch
1.56 x 1.56 mm
Viewing angle, vertical
160°
Viewing angle, horizontal
160°
Contrast ratio (typical)
3000:1
HD type
Full HD
Display brightness
500 cd/m²
Display resolution
1920 x 1080 pixels
Display technology
LED
Display diagonal
3.45 m (136")
Ports & interfaces
Remote (IR) input
1
RS-232C
Y
Wi-Fi
Y
Ethernet LAN (RJ-45) ports
1
Ethernet LAN
Y
USB version
2.0
USB ports quantity
1
USB port
Y
DisplayPorts in
1
DisplayPorts quantity
1
HDMI ports quantity
3
Audio
RMS rated power
18 W
Number of built-in speakers
2
Built-in speaker(s)
Y
Design
Mounting type
Wall
Orientation
Horizontal
Placement supported
Indoor
Product colour
Black
Product design
Digital signage flat panel
Performance
International Protection (IP) code
IP20
Ambient light sensor
Y
Purpose
Commercial
Power
Heat dissipation
5800 BTU/h
AC input frequency
50 / 60 Hz
AC input voltage
100 - 240 V
Power consumption (typical)
680 W
Computer system
Operating system installed
Web OS
Processor cores
4
Built-in processor
Y
Computer system type
System on Chip (SoC)
Computer system
Y
Weight & dimensions
Display weight
132 kg
Display height
1692 mm
Display depth
36.5 mm
Display width
3004 mm
Operational conditions
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
0 - 40 °C
Certificates
Certification
FCC, ETL, CB
Features
Video wall controller included
Y
Technical details
Sustainability compliance
Y
Sustainability certificates
CE, REACH, RoHS
Other features
USB connector type
USB Type-A
