75PK640S0LA

75-inch 4K UHD commercial signage display with built-in webOS 25, embedded content management, HDR10 Pro, Wi-Fi, and 16-7 duty rating for retail and corporate environments.

  • 75-inch 4K UHD (3840x2160) display with HDR10 Pro and HLG for vivid, high-impact signage content
  • Built-in webOS 25 SoC platform — operates as a standalone signage player with no external PC needed
  • Embedded Content and Group Manager lets you schedule and push content using only a remote or smartphone
  • Acts as a wireless access point for mobile devices and supports Beacon BLE for real-time customer promotions
  • Rated for 16-7 operation with a 30,000-hour backlight life — built for full business-hours commercial use
  • Compatible with LG SuperSign CMS and ConnectedCare for centralised multi-site management and remote monitoring
  • SKU:8806096558904
  • GTIN:8806096558904
  • MPN:75PK640S0LA

You need to login to view the price.

View full details
BRIGHTNESS300 nitsTypical
RUNTIME16-724 h x 7 days
VESA MOUNT300×300 mmVESA
ORIENTAIONLandscapeMounting
BEZEL WIDTH9.4 / 9.4 / 9.4 / 18 mmL / R / Top / Bottom

75-inch 4K UHD commercial TV signage

LG 75PK640S0LA

The LG 75PK640S is a 75-inch 4K UHD TV Signage display designed for commercial environments such as retail stores, corporate lobbies, quick-service restaurants, and hospitality venues. Powered by the built-in webOS 25 platform, it operates as a fully standalone signage solution — no external media player required. Embedded Content and Group Management software allows operators to schedule and manage playlists directly from a remote control, mouse, or mobile device. With HDR10 Pro, direct-lit LED backlighting, and Wi-Fi connectivity including a wireless access point function, the PK640S delivers vibrant 4K visuals and versatile deployment options in a slim, space-saving form factor rated for 16-hour-a-day, 7-days-a-week operation.

Built-in webOS 25 Standalone Platform

Built-in webOS 25 Standalone Platform

The PK640S runs LG's webOS 25, with an upgraded SoC (K25Lp Quad) and improved web engine, meaning no external media player is needed to deliver signage content. The intuitive graphical interface lets operators launch apps, manage content, and control the display directly from the screen — reducing hardware costs and cabling complexity. For end users, this translates to a simpler, more reliable setup: fewer points of failure, easier day-to-day operation, and smooth multitasking across signage tasks without relying on a separate PC.

PC-Free Content and Group Management

PC-Free Content and Group Management

The display has an embedded Content Manager (CM) and Group Manager (GM), allowing operators to edit playlists, set time schedules, and push content to multiple displays — all without a PC or separate CMS software licence. Group management works across a master display and sub-group displays. For venues running multiple screens (e.g. a multi-room hotel or a retail chain), this eliminates the need for a dedicated signage PC at every location, and day-to-day updates can be made using just a remote control or a smartphone on the same Wi-Fi network.

4K signage. Built-in webOS. Zero extra players.

16-7 duty rated · 30,000-hour backlight life · CE certified

HDR10 Pro and HLG for Vivid Content

HDR10 Pro and HLG for Vivid Content

The 75PK640S supports both HDR10 Pro and HLG (Hybrid Log-Gamma), the two primary HDR formats used in broadcast and digital signage content. HDR10 Pro extends the standard HDR10 specification with dynamic tone mapping, allowing the display to optimise brightness and contrast scene-by-scene. With a static contrast ratio of 1,200:1 and a dynamic ratio of up to 1,000,000:1, promotional content — product imagery, brand videos, and menu boards — is rendered with deeper blacks and more vivid highlights, making on-screen content more eye-catching and true-to-life in real retail and hospitality settings.

16-7 Duty Rating with 30,000-Hour Backlight Life

16-7 Duty Rating with 30,000-Hour Backlight Life

The PK640S is rated for 16 hours of continuous operation per day, 7 days a week — the standard duty cycle for semi-intensive commercial signage. The direct-lit LED backlight is rated for 30,000 hours of service life, which at 16 hours daily equates to over five years of use before expected brightness degradation. This makes the display well suited for retail stores, hotel lobbies, and corporate reception areas where the screen runs during all business hours without risk of premature panel wear or voided warranty from extended use.

Wireless Access Point and Content Sharing

Wireless Access Point and Content Sharing

Beyond standard Wi-Fi connectivity, the PK640S can function as a virtual wireless access point (Soft AP), serving as a local router for mobile devices in the vicinity. Combined with built-in Miracast screen sharing and Bluetooth Low Energy (BLE) Beacon support, this enables real-time promotional push to nearby smartphones and mirroring of content from mobile devices. In a retail context, this means shop staff can update displayed promotions or mirror product demonstrations from a phone without connecting any cables — and Beacon packets can trigger coupons or location-based notifications on customers' devices.

LG SuperSign CMS and ConnectedCare Compatibility

LG SuperSign CMS and ConnectedCare Compatibility

While the embedded CM-GM handles on-site management, the PK640S is fully compatible with LG SuperSign CMS (sold separately) for organisations that need a centralised, multi-site content management platform. Additionally, LG ConnectedCare provides cloud-based remote monitoring and fault diagnostics, allowing IT or AV teams to check display health, receive alerts, and apply remote fixes without a site visit. This makes it practical for deployments across multiple locations — a retail chain or hotel group can monitor all screens centrally and reduce costly on-site service calls.

Slim Design with Flexible Installation Options

Slim Design with Flexible Installation Options

At 59.8 mm depth (without stand) and a VESA 300×300 mm mounting pattern, the 75PK640S is straightforward to wall-mount in space-constrained locations. The slim profile ensures the display sits close to the wall, reducing visual intrusion and making it suitable for tight corridors, retail aisles, and meeting rooms. On-bezel width is 9.4 mm on three sides (18 mm bottom), and the off-bezel (screen-to-edge) measurement is just 7.3 mm on three sides — giving a clean, modern look when installed without a stand.

Fail-Over and DPM for Reliable Unattended Operation

Fail-Over and DPM for Reliable Unattended Operation

The PK640S supports automatic Fail-Over (fallback to a backup source if the primary signal is lost) and Display Power Management (DPM), which automatically powers the display on when a signal is detected and off when no signal is present. Combined with Time Scheduler and NTP Sync Timer, these features allow fully unattended operation on a pre-defined schedule — the display comes on with the store, shows content, and powers down at close, without any manual intervention. This is particularly valuable in unmanned kiosk or lobby deployments where hands-on management is not practical.

Display18 specifications
Display diagonal190.5 cm (75")
Display technologyLED (IPS panel)
LED backlighting typeDirect-LED
Resolution3840 x 2160 (4K UHD)
Brightness300 nits / 260 nits (Max. / Typ.)
Dynamic contrast ratio1,000,000:1
Static (panel) contrast ratio1,200:1 (typ.)
Response time8 ms (typ.), G to G
Refresh rate60 Hz
Backlight life30,000 Hrs, 16 Hrs / 7 Days
HDR (10 Pro / HLG)Yes (HDR10 Pro / HLG)
Aspect ratio16:9
TouchscreenNo
Display brightness300 cd/m²
HD type4K Ultra HD
Contrast ratio (typical)1200:1
Contrast ratio (dynamic)1000000:1
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 Pro (HDR10 Pro), Hybrid Log-Gamma (HLG)
Ports & interfaces14 specifications
HDMI ports quantity2
HDMI input version2.0 (HDMI In)
HDMI-ARCYes (ARC, HDMI2)
HDMI-CECSimplink (HDMI-CEC 1.4), HTNG-CEC
USB portYes (USB 2.0, USB-A), 1x
RS-232CYes
Ethernet LAN (RJ-45)Yes (usage purpose LAN), rear/bottom
Digital audio outOptical, rear/bottom
External speaker out3.5 mm phone jack (rear/bottom)
RF inYes (side, 75”)
CI slotYes (side)
IR outRS-232C phone jack type
Ethernet LAN (RJ-45) ports1
Number of antenna connectors1
Audio8 specifications
Speaker system2.0 ch
Audio output channels2.0 channels
Speaker sound output10 W + 10 W
Power per channel10 W
LG Sound SyncYes (Bluetooth or Optic)
Bluetooth audio playbackYes
Built-in speaker(s)Yes
Number of built-in speakers2
Design6 specifications
Front colourBlack
Stand type2 Poles
Tool nameUA75
Product typeNon-Touch Display
Product designInteractive table
Placement supportedIndoor
Performance10 specifications
Digital broadcasting systemDVB-T2/C/CI/S2
Analog broadcasting systemPAL / SECAM
TeletextAuto Teletext
Global IPTV supportYes (IP streaming)
Web browserYes
Vertical setupYes
Fail overYes
Play via URLYes
PurposeUniversal
Analog signal format systemATSC, NTSC, PAL, SECAM
Computer system2 specifications
Operating systemwebOS 25
SoCK25Lp (marketing name Quad)
Network6 specifications
Wi-FiWi-Fi (802.11ac)
BluetoothYes (Bluetooth Low Energy)
Screen share (Miracast)Yes
Soft AP (wireless access point)Yes
Smart ShareYes
DIALYes
Power11 specifications
Power supplyAC 100-240 V, 50-60 Hz
Power consumption (max.)201 W
Power consumption (typ.)170 W
Standby power consumptionUnder 0.5 W
Energy efficiency classF
Energy efficiency scaleA to G
Power consumption (typical)143 W
Power consumption (max)157 W
Energy efficiency class (HDR)G
Energy consumption (SDR) per 1000 hours108 kWh
Energy consumption (HDR) per 1000 hours170 kWh
Weight & dimensions11 specifications
Dimensions without stand (W x H x D)1,668 × 960 × 59.8 mm
Weight without stand23.5 kg
Dimensions with stand (W x H x D)1,668 × 1,031 × 344 mm
Weight with stand24 kg
VESA compatible300 × 300 mm
On bezel width (L/R/U/B)9.4/9.4/9.4/18 mm
Off bezel width (L/R/U/B)7.3/7.3/7.3/2.5 mm
Display width1668 mm
Display height960 mm
Width (with stand)1668 mm
Depth (with stand)1031 mm
Packaging data4 specifications
Shipping dimensions (W x H x D)1,875 × 1,150 × 175 mm
Shipping weight33.6 kg
Package width1875 mm
Package height1150 mm
Packaging content6 specifications
Stand includedYes (2 pole, detachable)
Remote control typeL-Con, AKB75095376
Power cable2 m (75”)
RS-232C to phone jack cableYes
Remote control includedYes
Cables includedAC, RS-232
Operational conditions2 specifications
Operating hours (hours/days)16/7
Backlight life30,000 Hrs, 16 Hrs / 7 Days
Certificates3 specifications
Safety certificationCB, CU TR
EMC certificationCE
Other certificationISTA6
Other features9 specifications
Smart functionswebOS25, Smart Home (launcher bar), Quick Access, Web Browser, Pre-loaded app (YouTube only), SDP server compatibility, SW clock, Mood Display, Smart Share, DIAL, Mobile Connection Overlay
Signage (Corporate / Retail)Vertical setup, Fail Over, Play via URL, Crestron certification compatibility, DPM, Time Scheduler, NTP Sync Timer, BEACON, Embedded CM, Embedded GM
SuperSign software compatibilityControl / Control Plus, CMS (Premium), Simple Editor, LG ConnectedCare
Hotel and installer functionsHotel Mode / PDM / Installer Menu, Lock Mode (limited), Port Block, Welcome Video, Welcome Screen, Insert Image, IP Channel Manager
Control and maintenance functionsUSB cloning, WOL, SNMP, self diagnostics (USB), SI compatible protocol (TV Link Tuner), Multi IR code, Auto Off / Sleep Timer, Energy Saving Mode
Real-time promotionBEACON / Bluetooth Low Energy (iBeacon / Eddystone)
Moving Picture PlaybackSD / HD / Plus HD
Motion Eye CareYes
EAN8806096558904
Technical details1 specification
Compliance certificatesFederal Communications Commission (FCC), UL

Specifications are checked against the manufacturer's documentation where available.
