AT-HDDA-8
AT-HDDA-8
- HDMI IN up to 15 meters (at1080p 8-bit) up to 50 feet HDMI OUT up to 10 meters (at1080p 12-bit) up to 30 feet
- HDMI In Features 3D, 4K, 1920x1200, Dolby TrueHD, DTS-HD Master Audio HDMI Out Features 3D, 4K, 1920x1200, Dolby TrueHD, DTS-HD Master Audio
- Ultra HD (4Kx2K)! 8 zones with analog and digital audio de-embedding, ideal for TV showrooms and digital signage using cutting-edge Ultra HD resolution.
- SKU:IM3_AT-HDDA-8
- GTIN/EAN:846352003722
- MPN:AT-HDDA-8
- Ultra HD for Vivid DetailsHDDA-8 passes 4Kx2K, the highest currently available resolution, plus Dolby TrueHD, DTS-HD Master Audio, and 3D up to 48-bit Deep Color. More Reliable Learns reference EDID from first connected output display and mirrors to all outputs ensuring an uninterrupted A/V signal. Locking HDMI and power connectors and optional redundant power supply add reliability. Audio de-embedding via 1 x S/PDIF and 1 x audio captive screw allows input to a commercial sound system in a sports bar or other hospitality or entertainment venue. For added ease of use, purchase the Atlona Link Connect Captive Screw Ready 2Ch Audio Cable (AT-LC-CS-2CH-2M)Additional Features Supports cascading up to 4x at1080p (4Kx2K cascading not supported)Link status LED for source and outputs Update in the field via USB port Dual purpose wall mount/rack brackets For added reliability use AT-PW5V3A-LOCK Optional Redundant Power Supply Compatibility Use with Atlona HDBaseT extender collection, HDBaseT distribution amplifier collection, or HDMI-to-HDMI matrix switcher collection AT-HDTX - Atlona HDBaseT TX HDMI BoxAT-HDRX - Atlona HDBaseT RX HDMI BoxAT-HDWP - Atlona HDBaseT RX HDMI 2-Gang US Wall PlateAT-HDWP-UK - Atlona HDBaseT RX HDMI 1-Gang UK Wall PlateAT-HDCAT-4 - Atlona 2 x 4 HDMI to HDBaseT Distribution AmplifierAT-HDCAT-8 - Atlona 2 x 8 HDMI to HDBaseT Distribution AmplifierAT-HDCAT-8ED - Atlona 2 x 8 HDMI to HDBaseT Extended Distance Distribution AmplifierAT-H2H-44M - Atlona 4 x 4 HDMI Matrix SwitcherAT-H2H-88M - Atlona 8 x 8 HDMI Matrix Switcher
Video out
8
Video port type
HDMI
Video ports quantity
8
Maximum resolution
4K
