Atlona AT-GAIN-M50-LZ

Atlona AT-GAIN-M50-LZ

Mixer Amplifier, 50 W, 2 x 25 W (stereo) or 1 x 50 W (bridged),

  • Two-Input mixer amplifier
  • 2 x 25 watts (stereo) or 1 x 50 watts (bridged) @ 4/8 ohms output
  • Duck audio on input 1 when signal detected on input 2
  • Mute audio with PA sense or contact closure
  • RS-232 control for integration with control systems
  • Compact, plenum rated enclosure
  • Optional AT-GAIN-VOL volume control wallplate
  • SKU:846352007683
  • GTIN/EAN:846352007683
  • MPN:AT-GAIN-M50-LZ

You need to login to view the price.

View full details

Atlona AT-GAIN-M50-LZ. Audio output channels: 1.0 channels, Amplifier class: D, Crosstalk (1kHz): -80 dB. Speakers connectivity type: 3.5mm, USB port type: USB Type-C, RS-232 connector type: 3-pin. Power source type: DC, AC input voltage: 100 – 240, AC input frequency: 50/60 Hz. Width: 219 mm, Depth: 152 mm, Height: 26 mm. Certification: CE, RoHS, FCC CE, FCC, UL, CUL, TUV-GS, CB, PSE, CCC

Two-input mixer amplifier
The Atlona AT-GAIN-M50-LZ is a two-input mixer amplifier designed for low impedance education and commercial applications. The amplifier features two unbalanced stereo audio inputs with independent level control and delivers either two channels of 25 watts each into 4 or 8 ohms, or a single channel of 50 watts.

Specialized Classroom Capabilities
Ducking automatically lowers the program audio level on input one when a teacher speaks into a microphone system connected to input two. PA sense or trigger mutes the output of the amplifier during public address announcements. Both features ensure important lesson material and announcements are heard clearly.

Audio
Audio output channels
1.0 channels
Amplifier class
D
Crosstalk (1kHz)
-80 dB
Frequency range
20 - 20000 Hz
Ports & interfaces
Speakers connectivity type
3.5mm
USB port type
USB Type-C
USB 2.0 ports quantity
1
DC-in jack
Yes
RS-232 connector type
3-pin
RS-232 ports
2
Technical details
Connectivity technology
Wired
Product colour
Black
Power
Power source type
DC
AC input voltage
100 – 240
AC input frequency
50/60 Hz
Power consumption (standby)
0.5 W
Power consumption (max)
64.3 W
Weight & dimensions
Width
219 mm
Depth
152 mm
Height
26 mm
Weight
880 g
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 90%
Indication
LED indicators
Yes
Certificates
Certification
CE, RoHS, FCCCE, FCC, UL, CUL, TUV-GS, CB, PSE, CCC
