Vaddio EasyIP Switch

Vaddio EasyIP Switch

Managed, L2 / L3, 16x Rj-45, 2x SFP, PoE, 185 W, 442 x 211 x 44.5 mm, 2.7 kg, EU cord, Black

  • Seamlessly Integrate with AV Rack Systems
  • Optimize Your Network with VLAN, QoS and PoE Management
  • Enhance Network Performance with Layer 3 Static Routing
  • Simply Plug and Play
  • Configured for use with Vaddio EasyIP Products
  • EasyIP Switches that ship are either the Luxul AMS-1208P or the Luxul AMS-1816P
  • PoE Self-Healing with auto-recovery and power scheduling
  • Layer 3 Static Routing
  • 802.1Q VLAN (with Trunking) and QoS Support
  • Plug-and-Play Installation with Intuitive Management
  • Simple Power Management of PoE-Enabled Devices
  • User Selectable Green or Blue Front facing LEDs
  • Fanless for Silent Operations
  • Standard 19” Rack-Mount
  • Three Year Limited Warranty
  • The RJ45 port surge protection is tested to: ENG1000-4-5 (for RJ45 port, surge 6KV)
  • SKU:0840077505974
  • GTIN/EAN:0840077505974
  • MPN:999-11208-001

You need to login to view the price.

View full details

Vaddio EasyIP Switch. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 12. Full duplex, Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

EasyIP Switch
The EasyIP Switch is preconfigured for use with Vaddio EasyIP products. The EasyIP Switch features rear panel ports and front facing LEDs (user selectable blue/green colors) for clean integration with AV rack systems. It is an excellent choice for expanding your network when using PoE-enabled devices such as VoIP, IP cameras and Wireless Access Points. The EasyIP Switch helps optimize your network with support for Layer 3 static routing between VLANs while also featuring simple-to-use management, VLAN and security capabilities to ensure optimal benefit from your home or office network.

This Package Includes:
- 12-port/8 PoE+ Gigabit Managed Switch or 18-port/16 PoE+ Gigabit Managed Switch. Please contact customer service for which unit is currently shipping.
- Power Cord
- Rack Mount Kit
- Quick Install Guide

3 years

Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
12
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Network
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported
Cat5, Cat5e, Cat6
Full duplex
Yes
VLAN support
Yes
Number of VLANs
4094
Design
Rack mounting
Yes
Stackable
No
Form factor
1U
Product colour
Black
LED indicators
Activity, Link, Power
Power
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
250 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
16
Total Power over Ethernet (PoE) budget
185 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
442 mm
Depth
211 mm
Height
44.5 mm
Weight
2.7 kg
Packaging content
Cables included
AC
Quick start guide
Yes
Rack mount kit
Yes
Certificates
Certification
FCC, IC, CE-EMC, CE-LVD, and RoHS
Logistics data
Harmonized System (HS) code
85176990
