Hannspree HO 325 PTB

Hannspree HO 325 PTB

31.5" TFT LED, IP55, 1920 x 1080 mm, 16:9, 400 cd/m², 2x 2 W, DisplayPort, HDMI, USB B, 45 W, 747 x 64.3 x 451.4 mm, 14.5 kg

  • 1920 x 1080 Full HD 1080P Resolution
  • 10-Point Touch P-Cap Technology
  • 178° / 178° Ultra Wide Viewing Angle
  • 400 cd/m² High Brightness Panel
  • Video Input: HDMI + Display Port
  • IP55 (front) Rating Level
  • Display Protection: Thickness 3mm
  • Built-in Speakers
  • ≥7H Toughened Hard Panel Surface
  • Slim Profile, Edge-to-Edge True Flat Surface
  • Metal chassis, frame and back cover
  • Touch-Through Glass (available upon request*)
  • VESA Mount and Multiple Mounting Options
  • Orientation: Landscape, Portrait, Face-Up
  • SKU:4711404023002
  • GTIN/EAN:4711404023002
  • MPN:HO325PTB
Add To Favorite

You need to login to view the price.

View full details

The HANNspree HO325PTB 32’’ 16:9 Open-Frame monitor delivers a high-performance display solution. Its rugged bezel with edge-to-edge glass makes it very suitable for applications like tabletop integration.

The HANNspree HO325PTB is an ideal display for integration in kiosk, totem and a perfect solution for interactive digital signage, In-store Retail, Gaming and many other sectors.

LIMITLESS POSSIBILITIES WITH OPEN FRAME

Designed for demanding environments, the HANNspree Open Frame series delivers a long life cycle, high resolution experience to a wide range of commercial and industrial applications. Featuring a molded metal casing to extra protection, these open-frame monitors have a long-lasting product life cycle, Digital video inputs along with VESA and or flange mount capability on selected models, the HANNspree Industrial Open-Frame family make the most of your digital world.

Choose from standard or touch screen high performance displays ranging from 10.1″ up to 55″ and the right aspect ratio to best fit your application.

TOUCH-THROUGH GLASS

Now multiple users can experience shared touchscreen interaction. Using up to 10 finger touchpoints, the HANNSpree HO325PTB Monitor allows everyone to play and collaborate at the same time.

The precise and accurate multi-touch display — allowing up to 10 simultaneous touches — allowing you to work smarter and more efficiently.

There’s no need for additional controllers – all they have to do is just reach out and touch the screen. It is certified for Windows 10 and designed to offer superior performance as well as intuitive control, so you can be more productive and do everything you want to do smoothly and quickly.

With Projected Capacitive Touch, users can enjoy a smoother and more accurate touch display experience with increased interactivity. Thanks to the glass overlay this technology is highly durable, the Touch performance is unaffected by everyday use and mishaps such as dirt, dust, condensation, liquid spills or cleaning solutions.

This technology delivers super-fast, sensitive touch response with excellent dragging performance and perfect picture quality. Ten-point multi-touch support lets you unlock the power of today’s touch-enabled applications.

MOUNTING OPTIONS

Its rugged bezel with edge-to-edge glass makes it very suitable for applications like tabletop integration. The display supports rear VESA and external mounting brackets for multiple mounting options. The brackets provide the benefits of easy installation and flexibility for different applications.
- Supports Multiple Mounting Options
- Slim profile with narrow edges

VIVID IMAGES, LIFELIKE VISUALS WITH ULTRA-WIDE VIEWING ANGLES

The Touch monitor HO325PTB features a 16:9 aspect ratio LED-backlit panel with a 178° ultra-wide view angle that minimizes colour shift on both horizontal and vertical planes to ensure quality visuals from almost any direction. It delivers improved colour accuracy plus increased energy efficiency.

The HO325PTB uses a 178°(H) / 178°(V) ultra-wide viewing angle Full HD panel that eliminates colour shift from almost any direction and in nearly every angle.

SCRATCH-RESISTANT – MULTI-TOUCH SCREEN WITH 7H SURFACE HARDNESS

7H scratch resistant surface hardness ensures durability, as well as a consistent high-quality touch experience.

Scratch resistance is essential for touch solutions used for education and public environment. This is achieved thanks to a glass overlay covering the screen. This means that the panel surface can withstand impact from objects and scratches, making it perfect for public spaces and educational institutions.

Our toughened Hard Glass fronted LED Monitors (7H hardness rating) are designed specifically for retail and Industrial applications offering protection from impacts and dirt for a long-life solution.

It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.

CONNECTIVITY

The HANNspree HO325PTB features a host of connectivity options that include VGA, HDMI and DP.

The HO325PTB Open Frame Touch Monitor ensures that your monitor is more compatible and ready to handle all of your content.

Enabling touch is easy! Simply connect the USB cable from your PC to the monitor’s USB upstream port, and connect one of the video inputs to project images onscreen.

Display
Vertical scan range
56 - 75 Hz
Horizontal scan range
31 - 83 kHz
Display number of colours
16.78 million colours
Maximum refresh rate
60 Hz
Contrast ratio (typical)
1200:1
Screen shape
Flat
Display brightness
400 cd/m²
Response time
8 ms
Touchscreen technology
Projected capacitive system
Backlight type
LED
Panel type
TFT
Display resolution
1920 x 1080 pixels
Display diagonal
80 cm (31.5")
Performance
AMD FreeSync
No
NVIDIA G-SYNC
No
Multimedia
RMS rated power
2 W
Number of speakers
2
Built-in speaker(s)
Yes
Design
Certification
CE
International Protection (IP) code
IP55
Glass thickness
3 mm
Housing material
Metal
Product colour
Black
Ports & interfaces
Audio output
Yes
Audio input
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
1
Ergonomics
Number of OSD languages
15
On Screen Display (OSD)
Yes
Wall mountable
Yes
VESA mounting
Yes
Power
Energy efficiency scale
A to G
Power supply type
AC
AC input frequency
50 / 60 Hz
AC input voltage
100 - 240 V
Power consumption (off)
0.24 W
Power consumption (max)
45 W
Power consumption (standby)
0.26 W
Power consumption (typical)
40 W
Energy consumption (SDR) per 1000 hours
21 kWh
Energy efficiency class (SDR)
D
Sustainability
European Product Registry for Energy Labelling (EPREL) code
403968
Weight & dimensions
Weight (without stand)
14.5 kg
Height (without stand)
64.3 mm
Depth (without stand)
451.4 mm
Width (without stand)
747 mm
Packaging data
Package weight
16.8 kg
Package height
577 mm
Package depth
163 mm
Package width
863 mm
Cables included
AC, HDMI, USB
Logistics data
Harmonized System (HS) code
85285210
Technical details
Compliance certificates
RoHS
Surface hardness
Surface hardness
7H
Display diagonal (metric)
80 cm
Built-in microphone
No
Pixel pitch
0.364 x 0.364 mm
Viewing angle, vertical
178°
Viewing angle, horizontal
178°
Contrast ratio (dynamic)
10000000:1
DisplayPorts quantity
1
HDMI ports quantity
1
HDMI
Yes
Number of simultaneous touchpoints
10
Touch technology
Multi-touch
Built-in camera
No
Display technology
LED
Native aspect ratio
16:9
HD type
Full HD
Touchscreen
Yes
