Intel Wi-Fi 6 AX200 (Gig+)

Intel Wi-Fi 6 AX200 (Gig+)

Intel® Wi-Fi 6 AX200 (Gig+), 2230, 2x2 AX+BT, vPro®

  • Wireless
  • PCI Express WLAN
  • 2400 Mbit/s
  • Wi-Fi Dual-band (2.4 GHz / 5 GHz) Bluetooth 5
  • Internal Component for: PC/Laptop
  • SKU:NET-IT/AX200/M2
  • GTIN/EAN:
  • MPN:AX200NGW

You need to login to view the price.

Add To Favorite
View full details

Intel Wi-Fi 6 AX200 (Gig+). Internal. Connectivity technology: Wireless, Host interface: PCI Express, Interface: WLAN. Maximum data transfer rate: 2400 Mbit/s, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi band: Dual-band (2.4 GHz / 5 GHz). Antenna type: 2x2

Intel® Wi-Fi 6 solutions enable the fastest wireless speeds for PCs, more responsive performance, with enhanced security and reliability, especially in dense environments. Benefits include fast uploads and downloads, lower latency and longer battery life compared to solutions supporting 802.11ac. Experience a dramatically improved connected experience at home, work, or on the go.

The new Intel® Wi-Fi 6 AX201 (Gig+) adapter supports 2x2 Wi-Fi 6 technology, including new features such as UL and DL OFDMA and 1024QAM, delivering increased network capacity as well as Bluetooth® 5.2 support.

Ports & interfaces
Interface
WLAN
Host interface
PCI Express
Connectivity technology
Wireless
Network
MU-MIMO
Yes
Bluetooth version
5
Bluetooth
Yes
Security algorithms
64-bit WEP, 128-bit AES, 128-bit WEP, 256-bit AES, AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, TKIP, WPA2, WPA3, WPS
Wi-Fi standards
Wi-Fi 6 (802.11ax)
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Wi-Fi
Yes
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Maximum data transfer rate
2400 Mbit/s
Design
Package size
22 x 30 x 2.4 mm
Antenna type
2x2
Component for
PC/Laptop
Internal
Yes
System requirements
Other operating systems supported
ChromeOS
Linux operating systems supported
Yes
Windows operating systems supported
Windows 10 x64
Compatible operating systems
Windows 10, 64-bit*|Linux*
Operational conditions
Operating temperature (T-T)
0 - 80 °C
Weight & dimensions
Weight
2.83 g
Height
2.4 mm
Depth
30 mm
Width
22 mm
Other features
Product codename
Cyclone Peak
Product series
Intel® Wireless Products
Launch date
Q2'19
Product brief URL
https://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/wi-fi-6-ax200-module-brief.pdf
Status
Launched
Harmonized System (HS) code
85176990
Supported Under vPro
Yes
Interface type
Wi-Fi(PCIe), BT(USB)
Product type
Wireless
Processor family
Intel Wi-Fi 6 Products
Export Control Classification Number (ECCN)
5A992CN3
Commodity Classification Automated Tracking System (CCATS)
G165483
Compliance
FIPS, FISMA
Maximum operating temperature
80 °C
