Quad-core Cortex-A7, Linux, 512MB RAM, 4GB eMMC, Wi-Fi, USB

  • Embedded OS : Linux
  • Wi-Fi : IEEE 802.11 a/b/g/n/ac
  • Connectivity : USB 2.0 Type A (1)
  • Work together with LG One:Quick Share Application and Compatible LG digital signage models
  • SKU:8806091298621
  • GTIN/EAN:8806091298621
  • MPN:SC-00DA

You need to login to view the price.

Add To Favorite
View full details

LG One:Quick Share
for your Wireless Screen Sharing

Experience a wireless screen sharing to compatible LG digital signage models.

Start Working with Simple and Easy Connecting
LG One:Quick Share is a wireless screen sharing solution available through LG Digital Signage*, USB transmission unit for PC (SC-00DA), and its app. With One:Quick Share, you can simply share personal PC screen to LG Signage with easy initial setup to use, as well as availability to manage LG Signage's basic functions.

Easy Pairing
Connect USB type dongle devices to LG Signage for auto pairing, and disconnect them. Just by doing so, these two are ready to be connected each other.

Plug and Play
Simply share your personal PC screen to the LG Signage by connecting the USB dongle device on the PC after pairing with the Signage.

Wireless Screen Share with Clicks
Through pressing the USB dongle button in different ways, you can simply share the PC screen, change to another's one, and can show up to 4 PC screens on the Signage at the same time.

Embedded Wi-Fi
With SoftAP function in LG Signage, USB dongle device and the Signage can be easily connected and used without additional transceiver.

Setting Without Remote Control
Without a remote control, you can adjust the default setting values of signage (volume, picture mode, auto bright, etc.) on the One:Quick Share PC application, as well as further edit the agenda/note, presentation settings displayed in Office Meeting Mode.

Screen Manager
Meeting organizer with admin privileges can manage screens shared on the Signage. You can change the order of the split screens, stop screen sharing, or even select the screen among other connected screens.

Mac operating systems supported
Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported
Mac compatibility
Operating system installed
Processor architecture
ARM Cortex-A7
Ports & interfaces
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB connector type
USB Type-A
USB version
USB ports quantity
Device interface
Power consumption (typical)
2 W
Power source
Product colour
Black, Blue
Internal memory type
Internal memory
512 MB
Storage media
Internal storage capacity
4 GB
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Weight & dimensions
46 g
63.8 mm
13.5 mm
63.8 mm
