LG 22XE1J-B

LG 22XE1J-B

21.5", Full HD (1920 x 1080), 16:9, IPS, 25 ms, HDMI, USB, RS-232C, RJ-45, 557.3 x 319.8 x 65 mm

  • Brightness (Typ, w/ Glass) : 1,500 nits
  • IP56 Rated Dust / Water Proof
  • 21.5" of Versatile Display Size
  • Wide Operating Temperature Range
  • webOS Smart Platform
  • Web-based Monitoring Solution
  • SKU:0195174014394
  • GTIN/EAN:0195174014394
  • MPN:22XE1J-B
Add To Favorite

You need to login to view the price.

View full details

High Visibility Under Bright Environments
With a brightness of 1,500 nits, 22XE1J boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.

21.5 inches of Versatile Screen Size
The small and light size of 21.5 inches allows for flexible use in various spaces. In particular, you can install the display in various way allowing for high utilization for small-medium businesses (SMB) to large businesses.

Secured Protection with IP56 Design
The display is sealed with IP56 design for reliable operation. It’s designed to be not only waterproof but also weatherproof against the damaging effects of the sun, rain, snow, dust and wind, which is an essential feature for outdoor application.

Wide Operating Temperature Range
22XE1J can be used under a wide range of operating temperatures which results in fewer constraints for outdoor installation.

Conformal Coating
Conformal Coating* improves reliability of the circuit board, power board by protecting it against dust, iron powder, humidity, etc.

Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.

High Performance with webOS
Quad Core SoC can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.

Easy Content Distribution
& SW Update

22XE1J features embedded Wi-Fi*, Bluetooth, Beacon making it easy to distribute content wirelessly and update Firmware. In particular, using Beacon and BLE (Bluetooth Low Energy), shop manager can do various promotional activities, such as providing promotional coupons or product information to visitor in real time.

Web Monitoring
(Control Manager)

This is a web-based monitoring solution, which provides a ease of control for the user. It enables users to have full access anywhere, anytime from their mobile phone & PC as long as they’re connected to a network while having access to both current and past data. It allows users to monitor the unit, make any adjustments and control it remotely in real-time.

LG's Simple Advertisement Helper, Promota
Using LG's Promota* application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more to your customers while recommending easy-to-use templates relevant to your industry.

Real-time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.

Display
RGB colour space
NTSC
Haze rate
25%
Native refresh rate
60 Hz
Surface hardness
3H
Rated lifetime
70000 h
Display number of colours
16.7 million colours
Viewing angle, vertical
178°
Viewing angle, horizontal
178°
Contrast ratio (typical)
1000:1
Response time
25 ms
Native aspect ratio
16:9
Touchscreen
No
HD type
Full HD
Display brightness
1500 cd/m²
Display resolution
1920 x 1080 pixels
LED backlighting type
Edge-LED
Display technology
IPS
Display diagonal
54.6 cm (21.5")
Ports & interfaces
RS-232C
Yes
Number of speaker outputs
1
Wi-Fi
Yes
Ethernet LAN (RJ-45) ports
1
USB version
2.0
USB ports quantity
1
USB port
Yes
DVI port
No
HDMI ports quantity
1
Design
Anti-glare screen
Yes
Panel mounting interface
100 x 100 mm
VESA mounting
Yes
Placement supported
Indoor/outdoor
Product colour
Black
Product design
Digital signage flat panel
Performance
HDCP
Yes
HDCP version
1.4
International Protection (IP) code
IP56
Operating hours (hours/days)
24/7
On Screen Display (OSD)
Yes
Number of OSD languages
21
On Screen Display (OSD) languages
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Portuguese, Russian, Swedish, Turkish
Purpose
Universal
Power
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power consumption (off)
0.5 W
Power consumption (standby)
0.5 W
Power consumption (typical)
85 W
Computer system
Operating system installed
WebOS
Internal memory
16 GB
Built-in processor
Yes
Computer system type
System on Chip (SoC)
Computer system
Yes
Weight & dimensions
Display weight
8.3 kg
Display height
319.8 mm
Display depth
65 mm
Display width
557.3 mm
Packaging data
Package weight
10 kg
Package height
394 mm
Package depth
187 mm
Package width
632 mm
Packaging content
Cables included
RS-232
Tilt adjustment
Yes
Power adapter included
Yes
Remote control included
Yes
Tilt angle
15°
Operational conditions
Operating relative humidity (H-H)
5 - 100%
Operating temperature (T-T)
-30 - 50 °C
Features
Harmonized System (HS) code
85285210
Technical details
Sustainability certificates
ErP
Compliance certificates
CE
