LG 75XE3C-B

LG 75XE3C-B

75", 3840x2160, HDMI, DP, DVI-D, RS-232C, RJ45, SD, USB 3.0, IP56, 1075.6x1991.6x218.9 mm

  • Outdoor Black
  • 190.5 cm (75") 3840 x 2160 pixels 3000 cd/m²
  • 8 ms
  • Ethernet LAN
  • SKU:8806087857382
  • GTIN/EAN:8806087857382
  • MPN:75XE3C-B

You need to login to view the price.

View full details

LG 75XE3C-B. Display diagonal: 190.5 cm (75"), Display resolution: 3840 x 2160 pixels, Display brightness: 3000 cd/m², HD type: 4K Ultra HD. Operating hours (hours/days): 24/7. Product colour: Black

Smart Brightness Control

The auto-brightness sensor and preset time scheduler save power whenever possible.


Advanced Local Dimming

The backlighting in specific areas of the screen can be controlled to increase contrast and provide a clearer image with twice the detail.



QWP (Quarter Wave Plate)

FPR (Film-type Patterned Retarder) technology is embedded with a QWP which enables clear visibility even when the viewer is wearing polarized sunglasses.


Wide Viewing Angle

IPS technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at virtually any angle.


No Blackening Effect

Even under direct sunlight exposure, LG commercial monitors remain free from blackening defects under 110°C and provide superior quality for outdoor usage.


Anti-reflection

Less interference between reflection of external light & back light thanks to anti-reflection coating.


Dust & Humidity Protection Designed with IP56 Rating

The conformal coating enhances circuit board reliability by protecting it from dust, iron shavings, humidity and other harsh conditions.


High Operating Temperature

The panel offers superb reliability under high operating temperatures and reduces cooling fan usage.
High Operating Temperature


Enhanced Thermal Management

Environmentally sealed structure for waterproofing and protecting againsts brake dust and fumes. Three-layer thermal management prevents heating from the LCD, Circuit / Power board and Solar loading. Totally self-contained and suitable for outdoor use without air filter.


7.5 mm Protective Glass

Designed to protect panel from impacts and vandalism for outdoor use. Features OCA* film to protect against heating in direct sunlight.


Low Power Consumption Using The M+ Panel

The M+ panel offers excellent energy efficiency and cost savings and decreases power consumption by approx. 31 compared to conventional RGB panels*.


Web Monitoring

The embedded web monitoring allows a variety of parameters to be diagnosed in real time using temperature, pixel, door, ambient light and gyro sensors. It can be easily controlled at all times.


Optional Stand

It is designed with various applications in mind and compatible with wall mounted landscape/portrait orientation. Optional stand to allow panel to stand freely and facilitate easy cable management.

Display
Display diagonal
190.5 cm (75")
Display resolution
3840 x 2160 pixels
Display brightness
3000 cd/m²
HD type
4K Ultra HD
Native aspect ratio
16:9
Response time
8 ms
Contrast ratio (typical)
1200:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Ports & interfaces
HDMI ports quantity
1
DVI port
Yes
DVI-D ports quantity
1
DisplayPorts quantity
2
USB port
Yes
USB version
3.2 Gen 1 (3.1 Gen 1)
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
PC Audio in
Yes
RS-232C
Yes
Card reader integrated
Yes
Compatible memory cards
SD
Audio
Built-in speaker(s)
No
Design
Product colour
Black
Placement supported
Outdoor
Orientation
Vertical
Bezel width (top)
11 cm
Bezel width (side)
7.33 cm
Bezel width (bottom)
23 cm
Performance
Operating hours (hours/days)
24/7
International Protection (IP) code
IP56
Power
Power consumption (typical)
700 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Weight & dimensions
Width
1075.6 mm
Depth
218.9 mm
Height
1991.6 mm
Weight
180 kg
Packaging data
Package width
1308 mm
Package depth
468 mm
Package height
2296 mm
Packaging content
Remote control included
Yes
Cables included
HDMI, RS-232, USB
Operational conditions
Operating temperature (T-T)
-30 - 50 °C
Operating relative humidity (H-H)
5 - 100%
Certificates
Certification
UL / cUL / CB
FCC Class "A" / CE / KCC
Features
Harmonized System (HS) code
85285210
Other features
User memory
8 GB
Built-in brightness sensor
Yes
Temperature indicator
Yes
Glass protection
Yes
