Netgear MS108UP

Netgear MS108UP

MS108UP - 8-port Multi-Gigabit (2.5G) Ultra60 PoE++ Ethernet Unmanaged Switch

  • Multi-Gigabit Ethernet
  • Non-Blocking Switching
  • PoE Support
  • Fanless Design
  • PoE Auto-Balance
  • Versatile Mounting Options
  • SKU:606449156898
  • GTIN/EAN:606449156898
  • MPN:MS108UP-100EUS
Add To Favorite

You need to login to view the price.

View full details

NETGEAR MS108UP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt,.... DC input voltage: 54 V. Power over Ethernet (PoE). Wall mountable

NETGEAR brings the first Unmanaged
Multi-Gigabit PoE++ switch MS108UP with 60Watts per port Ultra60 PoE++ technology, ideal for powerful PoE++ installations with PoE budgets up to 230W, a compact size, plug-and-play
installation, and reliable performance at affordable prices. The new model MS108UP supports 2.5 Gigabit speed connectivity and Power-Over-Ethernet (PoE) that can provide up to 60W/port. The new switch model can power devices such as VoIP phones, surveillance IP cameras, wireless access
points and many other applications. This new Unmanaged switch provides PoE Auto-Balance to help automatically balance the PoE power based on the device needs independent of PoE class detected. With the growing deployment of applications and an allin-one solution, providing multi-speed and high power to these applications would be ideal.

Management features
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Ports & interfaces
2.5G Ethernet (copper) ports quantity
8
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity
8
Network
Number of VLANs
64
VLAN support
Yes
Auto-sensing
Yes
Ethernet LAN data rates
100,1000,2500 Mbit/s
Auto MDI/MDI-X
Yes
Head-of-line (HOL) blocking
Yes
Full duplex
Yes
Half duplex
Yes
10G support
No
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Data transmission
Packet buffer memory
1.5 MB
Packet forwarding rate (1 Gbps)
1488000 pps
Jumbo frames
12000
Jumbo frames support
Yes
Latency (1 Gbps)
3.593 µs
Switching capacity
40 Gbit/s
MAC address table
16000 entries
Design
Electromagnetic compatibility
CE, FCC part 15 Class B, ISED, VCCI, KC, CCC, BSMI, RCM
Wall mountable
Yes
Number of fans
0 fan(s)
LED indicators
Activity, Link, PoE, Power
Housing material
Metal
Rack mounting
No
Performance
Mean time between failures (MTBF)
373643.7 h
Fanless
Yes
Power
Input current
4.7 A
DC input voltage
54 V
Power supply included
Yes
Power source
DC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
230 W
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE)
Yes
Operational conditions
Heat dissipation
923.49 BTU/h
Operating altitude
0 - 3000 m
Operating relative humidity (H-H)
0 - 90%
Storage temperature (T-T)
-20 - 70 °C
Operating temperature (T-T)
0 - 40 °C
Weight & dimensions
Weight
900 g
Height
40 mm
Depth
140 mm
Width
210 mm
Certificates
Certification
CB, CSA, CCC, BSMI, RCM
Logistics data
Harmonized System (HS) code
85176990
