Netgear GS516PP

Netgear GS516PP

Gigabit Ethernet, 802.3at PoE+ Ports x16, 32 Gbps, 2 fans

  • PLUG-AND-PLAY - Simple set up with no software or configuration needed
  • POWER-OVER-ETHERNET: 16 PoE+ ports with 260W total power budget
  • STURDY METAL CASE - Small, sturdy desktop metal case and quiet operation
  • EASY-MONITORING - Per port LEDs for port activity and speed
  • GIGABIT ETHERNET – 16 auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with up to 32Gb non-blocking switching
  • PoE AUTO-BALANCE - unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected. The switches deliver the power the device needs, at the most granular level
  • SKU:606449149258
  • GTIN/EAN:606449149258
  • MPN:GS516PP-100EUS

You need to login to view the price.

View full details

NETGEAR GS516PP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u. Power over Ethernet (PoE). Rack mounting

Instant Connectivity and Reliable Performance
The NETGEAR Gigabit Unmanaged Switch series helps your business cost-effectively expand your network to Gigabit speeds and higher port counts. The GS516PP joins the series and offers 16 PoE+ ports to power high-power PoE devices. With a total PoE power budget of 260W, deploy denser PoE+ devices to a single switch rather than multiple

The GS516PP is energy efficient, built to last, and rigorously tested to provide the reliability your business needs. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.

Powerful and Energy Efficient
Ideal for powering and connecting VoIP phones, wireless access points, IP Cameras and IoT devices. Desktop or rackmount for flexible placement. The GS516PP gives you a highly cost-effective and powerful switch with the best cost/PoE budget ratio.

NETGEAR Unmanaged Switches support the latest Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected. It can further save energy when a short cable is used.

Limited Lifetime

Management features
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
16
Network
Auto MDI/MDI-X
Yes
Full duplex
Yes
Half duplex
Yes
Copper ethernet cabling technology
10GBASE-T, 100BASE-T, 1000BASE-T
10G support
No
Networking standards
IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Data transmission
Packet buffer memory
0.192 MB
Packet forwarding rate (1 Gbps)
1448000 pps
Jumbo frames
9216
Jumbo frames support
Yes
Latency (1 Gbps)
12 µs
Switching capacity
32 Gbit/s
MAC address table
8000 entries
Security
Queue scheduling algorithms
Weighted Round Robin (WRR)
Design
Number of fans
2 fan(s)
LED indicators
Activity, Fan fail, Link, PoE, Power, Speed
Housing material
Metal
Product colour
Blue, Grey
Rack mounting
Yes
Performance
Mean time between failures (MTBF)
2415333.9 h
Power
Power consumption (max)
316.1 W
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power supply included
Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
260 W
Power over Ethernet (PoE) power per port
30 W
Power over Ethernet plus (PoE+) ports quantity
16
Power over Ethernet (PoE) type supported
PoE+
Power over Ethernet (PoE)
Yes
Operational conditions
Operating altitude
0 - 3000 m
Storage relative humidity (H-H)
10 - 95%
Operating relative humidity (H-H)
10 - 90%
Storage temperature (T-T)
-20 - 70 °C
Operating temperature (T-T)
0 - 50 °C
Weight & dimensions
Weight
2.3 kg
Height
43 mm
Depth
207 mm
Width
330 mm
Certificates
Certification
FCC 47 CFR Part15B (Class A)ICES-003 Class AEN 55024/55032/55035 (Class A)AS/NZS CISPR 32VCCIBSMI CNS13438KCCUL 62368-1CB_IEC 60950-1 + IEC 62368-1 Ed-3LVD EN60950-1+EN62368-1 Ed-2 RptAS/NZS 62368.1 Ed-2BSMI CNS14336-1
Logistics data
Harmonized System (HS) code
85176990
