Netgear GS116PP

Netgear GS116PP

16x 10/100/1000 Base-T RJ45 ports, 16x PoE/PoE+ 802.3af/802.3at Ports, PoE Budget 183W, PSU 200W, Fanless, Desktop, Wall/Rack mount

  • Unmanaged
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • MAC address table: 4000 entries Switching capacity: 32 Gbit/s
  • Rack mounting
  • DC/PoE Power over Ethernet (PoE)
  • SKU:606449133332
  • GTIN/EAN:606449133332
  • MPN:GS116PP-100EUS

You need to login to view the price.

View full details

NETGEAR GS116PP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 4000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x. DC input voltage: 54 V. Power over Ethernet (PoE). Rack mounting

Instant Connectivity with Reliable Performance
The NETGEAR Gigabit Unmanaged Switch series helps businesses cost-effectively expand their network to Gigabit speeds and higher port counts. These unmanaged Gigabit switches come in a wide range of models including desktop, wall-mount and rackmount form factors and 5 to 24 port configurations.

They are energy efficient, built to last, and rigorously tested to provide the reliability businesses need. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.

High quality components and Energy Efficiency
Unmanaged Gigabit switches are built with Top Quality components to assure a long life. Unmanaged switches are built to last, and rigorously tested to provide the reliability businesses need.

NETGEAR Unmanaged Switches also support the latest Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active ports or when there is no link or no activity detected. It can further save energy when a short cable is used.

PoE+ Support (GS108LP,GS108PP,GS116LP,GS116PP)
Power-Over-Ethernet (PoE) and PoE+ options available for powering IP Security Cameras, VoIP phones, wireless access points, and other Ethernet-powered devices.

These PoE+ Switches are not just flexible in terms of placement they are also flexible in terms of PoE Power. Thanks to the interchangeable external Power Supply and with a built-in PoE selector they allow you to increase or decrease the PoE budget at any time.

The flexible mounting system gives you the flexibility to place them in a desktop environment, mounted in a rack (accessories included) or wall-mounted.

Management features
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
16
Network
Ethernet LAN data rates
10,100,1000 Mbit/s
10G support
No
Networking standards
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Data transmission
Switching capacity
32 Gbit/s
MAC address table
4000 entries
Design
Number of fans
1 fan(s)
LED indicators
Yes
Product colour
Black
Rack mounting
Yes
Performance
Mean time between failures (MTBF)
2088514 h
Buffer size
1000 KB
Power
Power consumption (typical)
200 W
Input current
3.7 A
DC input voltage
54 V
Power source
DC/PoE
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
183 W
Power over Ethernet plus (PoE+) ports quantity
16
Power over Ethernet (PoE)
Yes
Operational conditions
Heat dissipation
680.58 BTU/h
Operating altitude
0 - 3000 m
Storage relative humidity (H-H)
0 - 95%
Operating relative humidity (H-H)
0 - 90%
Storage temperature (T-T)
-20 - 70 °C
Operating temperature (T-T)
0 - 40 °C
Weight & dimensions
Weight
880 g
Height
27 mm
Depth
102 mm
Width
286 mm
Certificates
Certification
CE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1
Logistics data
Harmonized System (HS) code
85176990
