Netgear GS308PP

Netgear GS308PP

8-Port Gigabit Ethernet Unmanaged PoE+ Switch with FlexPoE

  • ETHERNET PORT CONFIGURATION: 8 Gigabit ports
  • POWER-OVER-ETHERNET: 8 PoE+ ports with 83W total power budget, and includes NETGEAR FlexPoE making it expandable to 123W (w/separately purchased power supply module)
  • PLUG-AND-PLAY: Simple set up with no software to install or configuration needed
  • PoE POWER AUTO-BALANCE AND ALLOCATION – NETGEAR’s unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs
  • VERSATILE MOUNTING OPTIONS: Supports desktop, wall or rackmount placement, and includes all the necessary mounting hardware in the box
  • SILENT OPERATION: The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
  • ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Most models are compliant with IEEE802.3az Energy Efficient Ethernet mode
  • BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance
  • SKU:606449146851
  • GTIN/EAN:606449146851
  • MPN:GS308PP-100EUS

You need to login to view the price.

View full details

NETGEAR GS308PP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 4000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable, Rack mounting

NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches with PoE provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly.

The unmanaged switches provides power and data from a single Ethernet (CAT-5e) cable to devices such as IP cameras, VoIP/ Internet-based phones, wireless access points, etc. The majority of these models also support PoE power auto-balance and allocation feature.

NETGEAR’s unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected. These switches deliver the power the device needs, at the most granular level

3-year

Management features
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Ports & interfaces
Power connector
DC-in jack
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
8
Network
Auto-sensing
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
Full duplex
Yes
10G support
No
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Data transmission
Packet buffer memory
0.192 MB
Packet forwarding rate (1 Gbps)
1448000 pps
Jumbo frames
9216
Jumbo frames support
Yes
Latency (1 Gbps)
3 µs
Switching capacity
16 Gbit/s
MAC address table
4000 entries
Design
Wall mountable
Yes
LED indicators
Activity, Link, PoE, Power, Speed
Housing material
Metal
Product colour
Black
Rack mounting
Yes
Performance
Mean time between failures (MTBF)
2752476 h
Power
Power consumption (max)
87.9 W
Input current
1.66 A
DC input voltage
54 V
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
130 W
Power over Ethernet (PoE) power per port
30 W
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE) type supported
PoE+
Power over Ethernet (PoE)
Yes
Operational conditions
Heat dissipation
300.6 BTU/h
Operating altitude
0 - 3000 m
Operating relative humidity (H-H)
0 - 90%
Storage temperature (T-T)
-20 - 70 °C
Operating temperature (T-T)
0 - 40 °C
Weight & dimensions
Weight
600 g
Height
27 mm
Depth
102 mm
Width
236 mm
Certificates
Certification
CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI,BSMI, KC
Logistics data
Harmonized System (HS) code
85176990
