Netgear XSM4344FC

Netgear XSM4344FC

SFP+, 10G, 420W, L3, QSFP28, 1U

  • 420W internal power supply.
  • 1 slot for modular power supply (1+1 redundancy).
  • Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used.
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
  • Layer 3 feature set includes static, policy-based, and dynamic routing.
  • NETGEAR IGMP Plus™, NETGEAR AV OS, and Engage Controller speed up AV installations.
  • SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
  • Multi-color LED on each physical port reflecting the profile color in the NETGEAR AV OS™ and Engage Controller.
  • SKU:606449172942
  • GTIN/EAN:606449172942
  • MPN:XSM4344FC-100NES

You need to login to view the price.

View full details

NETGEAR XSM4344FC. Switch type: Managed, Switch layer: L3. Installed SFP+ modules quantity: 40, Console port: USB. Switching capacity: 1600 Gbit/s. Rack mounting, Form factor: 1U

POWER AND
THROUGHPUT
Edge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350

FOCUS ON THE EVENT
NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.

MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTS
Enable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.

Management features
Switch type
Managed
Switch layer
L3
Ports & interfaces
Installed SFP+ modules quantity
40
Fiber ports quantity
44
Fiber optic connector
QSFP28, SFP+
Console port
USB
QSFP28 ports quantity
4
Network
10G support
Yes
Data transmission
Switching capacity
1600 Gbit/s
Jumbo frames support
Yes
Security
IGMP proxy
Yes
IGMP snooping
Yes
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Black
Performance
Memory type
DDR4-SDRAM
Internal memory
4000 MB
Noise level
69.5 dB
Power
Power source
AC
Power supply included
Yes
Power consumption (max)
213.6 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Heat dissipation
728.21 BTU/h
Weight & dimensions
Width
440 mm
Depth
400 mm
Height
43.2 mm
Weight
7.38 kg
Packaging content
Cables included
AC, USB
Manual
Yes
Rack mount kit
Yes
