Vaddio PrimeSHOT 10 HDMI

Vaddio PrimeSHOT 10 HDMI

10x zoom, 2.14 million, 1/2.8-Type Exmor CMOS Sensor, 16:9 and 4:3, HDMI 1.4b, H.264, white

  • 10x zoom with 67 degree horizontal field of view
  • Simultaneous HDMI and H.264 (RTSP or RTMP) IP streaming outputs
  • Video image adjustments such as manual color compensation, saturation and iris
  • Custom PTZ presets
  • Free Vaddio Deployment Tool for remote management, updates and more
  • SKU:0840077508265
  • GTIN/EAN:0840077508265
  • MPN:999-30410-001

You need to login to view the price.

View full details

Vaddio PrimeSHOT 10 HDMI. Megapixel (approx.): 2.14 MP, Sensor type: CMOS. HD type: Full HD, Maximum video resolution: 1920 x 1080 pixels, Supported video modes: 720p, 1080p, Maximum frame rate: 60 fps. Optical zoom: 10x. Product colour: Black

Vaddio’s PrimeSHOT 10 HDMI camera offers high-definition performance at an outstanding value. Ideal for meeting rooms, lecture halls and houses of worship, PrimeSHOT 10 HDMI provides outstanding low-light performance, and excellent 1080p image quality.

With simultaneous HDMI and IP streaming outputs, the PrimeSHOT 10 can broadcast the stream directly to your preferred live streaming client and send video to a local display for easy IMAG (image magnification).

PrimeSHOT 10 HDMI features 10x optical zoom, plus an easy, intuitive web-based user interface for remote configuration, management and control. Customizable PTZ presets and controls make PrimeSHOT 10 perfect for rooms with multiple focus points.

3 years

Camera
Megapixel (approx.)
2.14 MP
Sensor type
CMOS
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Optical zoom
10x
Horizontal field of view (tele)
3.1°
Horizontal field of view (wide)
67°
Minimum illumination
100 lx
Signal-to-Noise Ratio (SNR)
50 dB
Aperture number of steps
16
White balance
Auto, Manual, One push
Focus adjustment
Auto/Manual
Wide Dynamic Range (WDR)
Yes
Number of camera presets
16
Back Light Compensation (BLC)
Yes
Gain control type
Auto/Manual
PTZ control
Yes
Aspect ratio
4:3, 16:9
Maximum working distance (tele)
100 cm
Minimum working distance (wide)
1 cm
3D NR (Noise Reduction)
Yes
Video
Maximum video resolution
1920 x 1080 pixels
Maximum frame rate
60 fps
HD type
Full HD
Resolution at capture speed
1920x1080@60fps
Supported video modes
720p, 1080p
Video formats supported
H.264
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Design
Product colour
Black
Tilt angle range
-30 - 90°
Pan range
0 - 165°
Web-based management
Yes
Tilt speed (max)
90 °/sec
Pan speed (max)
90 °/sec
Ports & interfaces
HDMI ports quantity
1
HDMI version
1.4
RS-232 ports
1
Ethernet LAN (RJ-45) ports
1
Power
Power source type
DC
DC input voltage
12 V
Input current
1.5 A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
20 - 80%
Packaging content
Remote control included
Yes
Cables included
AC
AC adapter included
Yes
Quick start guide
Yes
Audio
Noise reduction
Yes
Performance
Remote control function
Yes
Certification
CE, FCC, TAA
Weight & dimensions
Width
155 mm
Depth
145 mm
Height
163 mm
Weight
1.36 kg
