Vaddio RoboSHOT 40 UHD 4K PTZ Camera System

Vaddio RoboSHOT 40 UHD 4K PTZ Camera System

RoboSHOT 40 UHD, 1/2.5 Exmor CMOS , 2160p/29.97, 40x Zoom, F2, 1.6 Lux, White

  • Broadcast TV, corporate broadcast, local TV stations, campus news
  • Churches, houses of worship
  • Live events
  • Sporting events such as high school football or soccer
  • Large auditoriums
  • Concert halls
  • SKU:0840077503956
  • GTIN/EAN:0840077503956
  • MPN:999-9952-001W

You need to login to view the price.

View full details

Vaddio RoboSHOT 40 UHD 4K PTZ Camera System. Megapixel (approx.): 8.51 MP, Sensor type: CMOS. HD type: 4K Ultra HD, Maximum video resolution: 3840 x 2160 pixels, Supported video modes: 1080p, 2160p, Maximum frame rate: 29.97 fps. Optical zoom: 40x. Product colour: Black

The production-quality RoboSHOT 40 UHD PTZ camera provides brilliant 4K video footage for broadcasting or live streaming applications.

RoboSHOT 40 UHD offers 40x zoom, genlock capabilities, ultra-smooth motor movement and outstanding image quality – all at a surprisingly competitive price for the entry-level broadcast PTZ camera market.

Designed with a genlock external sync port, the RoboSHOT 40 UHD camera provides accurate synchronization in multi-camera broadcast environments, plus phase compensation to fine-tune and adjust the genlock signal.

In addition to an incredible 30x zoom with 4K resolution at 30fps, it provides full high definition 40x zoom with 1080p/60fps performance with the latest advancements in digital super resolution zoom.

With its 4K Exmor R CMOS image sensor, RoboSHOT 40 UHD offers more powerful image signal processing (ISP) – resulting in better light-gathering capabilities, incredible contrast and sharp 4K video, even in dim lighting conditions. Expect exceptional performance in the presence of high intensity spotlights seen in performance halls, live event venues, and night-time outdoor sporting events.

RoboSHOT 40 UHD offers silky-smooth, silent pan-tilt-zoom motion, thanks to Vaddio’s next generation silent motors paired with Tri-Synchronous motion algorithms. Even at full zoom, the RoboSHOT 40 UHD moves with no jitter or bouncing.

2 years

Camera
Megapixel (approx.)
8.51 MP
Sensor type
CMOS
Optical sensor size
25.4 / 2.5 mm (1 / 2.5")
Optical zoom
40x
Horizontal field of view (tele)
4.1°
Horizontal field of view (wide)
70.2°
Minimum illumination
1.6 lx
Signal-to-Noise Ratio (SNR)
50 dB
White balance
ATW, Auto, Indoor, Manual, One push, Outdoor
Focus adjustment
Auto/Manual
Number of camera presets
17
Gain control type
Auto/Manual
PTZ control
Yes
Video
Maximum video resolution
3840 x 2160 pixels
Maximum frame rate
29.97 fps
HD type
4K Ultra HD
Supported video modes
1080p, 2160p
Design
Product colour
Black
Tilt angle range
-30 - 90°
Pan range
-160 - 160°
LED indicators
Power
Tilt speed (min)
0.35 °/sec
Tilt speed (max)
120 °/sec
Pan speed (min)
0.35 °/sec
Pan speed (max)
120 °/sec
Ports & interfaces
HDMI ports quantity
1
RS-232 ports
1
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
3G-SDI output
Yes
Power
Power source type
PoE
DC input voltage
12 V
Input current
3 A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Network
Network streaming
Yes
Packaging content
Remote control included
Yes
Cables included
AC
Control adapter
Yes
Mounting kit
Yes
Quick start guide
Yes
Technical details
Harmonized System (HS) code
85258900
Weight & dimensions
Width
203.2 mm
Depth
139.7 mm
Height
200.7 mm
Weight
2.72 kg
