SoundTube Entertainment SM500I-II-WX-BK

SoundTube Entertainment SM500I-II-WX-BK

SoundTube 5.25" Extreme Weather Outdoor Surface Mount Speaker in Black with BroadBeam Tweeter

  • 75 W
  • 86 - 22000 Hz 4 Ω
  • Acrylonitrile butadiene styrene (ABS)
  • Black
  • SKU:SM500I-II-WX-BK
  • GTIN/EAN:
  • MPN:SM500I-II-WX-BK

You need to login to view the price.

View full details

SoundTube Entertainment SM500I-II-WX-BK. Recommended usage: Universal. Connectivity technology: Wired. RMS rated power: 75 W, Frequency range: 86 - 22000 Hz, Impedance: 4 Ω, Sensitivity: 83 dB. Product colour: Black

SoundTube®'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille to keep water from the drivers and internal electronics in even the most extreme weather conditions. The SM500I-II-WX utilizes the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity as well as BroadBeam® waveguide technology to deliver a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker. The SM500I-II-WX has one 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid™ cooling. The speakers 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs and the six-position selectable tap switch for 25-, 70.7- and 100-volt applications provides easy access. The included SM500i-II-WX Stealth™ bracket mounting system with vertical and horizontal pivoting allow the SM500i-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall. Safety cable with speaker mounting bolt, Euroblock connector, wall mount bracket and terminal weather boot are included. IP-Rating: IP44.

Loudspeakers
Speaker placement
Surface-mountable
Tweeter
Yes
Tweeter diameter (imperial)
2.54 cm (1")
Woofer
Yes
Woofer diameter
13.3 cm
Woofer diameter (imperial)
13.3 cm (5.25")
Audio
RMS rated power
75 W
Frequency range
86 - 22000 Hz
Impedance
4 Ω
Sensitivity
83 dB
Crossover frequency
3000 Hz
Performance
Product colour
Black
Recommended usage
Universal
Housing material
Acrylonitrile butadiene styrene (ABS)
International Protection (IP) code
IP44
Certification
CE, RoHS, UL1480A
Amplifier
Amplifier
No
Ports & interfaces
Connectivity technology
Wired
Bluetooth
No
Weight & dimensions
Height
289.6 mm
Diameter
21.2 cm
Packaging data
Package type
Box
Package height
311.1 mm
Package weight
4.76 kg
Packaging data
Package width
266.7 mm
Package depth
342.9 mm
Packaging content
Quantity per pack
1 pc(s)
Sustainability
Sustainability certificates
CE, RoHS
