Teltonika TRB500 gateway/controller 10, 100, 1000 Mbit/s

Teltonika TRB500 gateway/controller 10, 100, 1000 Mbit/s

5G, 1x RJ-45, VPN, DNP3, RutOS

  • The TRB500 gateway is a compact-sized and energy-efficient industrial gateway with a Gigabit Ethernet interface and two configurable I/Os, allowing high-level customization and implementation of a multitude of scenarios
  • This device enables 5G network speeds with ultra-low latency for mission-critical infrastructures and high data throughput, ensured by 4 external antennas that allow the use of 4x4 MIMO
  • TRB500 comes with the RutOS operating system, which provides advanced security features and compatibility with our Remote Management System (RMS) for optimized remote management and monitoring capabilities of large fleets of devices
  • SKU:TRB500000000
  • GTIN/EAN:
  • MPN:TRB500000000

You need to login to view the price.

View full details

Teltonika TRB500. Product colour: Stainless steel, Enclosure material: Aluminum, Mounting type: DIN-rail/Wall mounting. Antenna type: External, Antenna connector type: SMA. Processor frequency: 1500 MHz, Internal memory: 256 MB, Flash memory: 512 MB. Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP,..., Routing protocols: NHRP, BGP, EIGRP, OSPFv2, RIP-1, RIP-2. Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X)

5G
Ultra-high cellular speeds of up to 1 Gbps

SA & NSA
Supports both architectures to leverage the 5G infrastructure

ULTRA-LOW LATENCY
Single-digit latency for mission-critical applications

GIGABIT ETHERNET
Reliable communication for high data throughput

COMPACTNESS
One of the smallest 5G gateways available in the market

FUTURE-PROOFING
Backward compatible with 4G (LTE CAT 20) and 3G network technologies

Design
Product colour
Stainless steel
Enclosure material
Aluminum
Mounting type
DIN-rail/Wall mounting
LED indicators
LAN, Power, Signal strength, Status
International Protection (IP) code
IP30
Features
Antenna type
External
Antennas quantity
4
Short Message Service (SMS)
Yes
Features
Antenna connector type
SMA
Performance
Control display unit
No
Built-in processor
Yes
Processor frequency
1500 MHz
Internal memory
256 MB
Flash memory
512 MB
Protocols
Routing protocols
NHRP, BGP, EIGRP, OSPFv2, RIP-1, RIP-2
Supported network protocols
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL)
Network
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Dynamic DNS (DDNS)
Yes
Security
MAC address filtering
Yes
Network address translation (NAT)
Yes
VLAN support
Yes
DoS attack prevention
Yes
Firewall security
Yes
Ports & interfaces
SIM card type
MiniSIM
SIM card slot
Yes
Number of simultaneous SIM cards
1
Ethernet LAN (RJ-45) ports
1
Management features
Syslog
Yes
Web-based management
Yes
Reset button
Yes
Power
Power consumption (max)
6 W
DC input voltage
9 - 30 V
Weight & dimensions
Height
30 mm
Depth
93.4 mm
Width
100 mm
Weight
241 g
Packaging content
Cables included
LAN (RJ-45), Micro-USB
Quick start guide
Yes
AC adapter included
Yes
Operational conditions
Operating temperature (T-T)
-40 - 75 °C
Operating relative humidity (H-H)
10 - 90%
