Nexmosphere X-Touch, 1 large button, Rectangular, White LED, 180cm cable
Nexmosphere X-Touch, 1 large button, Rectangular, White LED, 180cm cable
X-Touch, 1 large button, Rectangular, White LED, 180cm cable
- Works with multiple materials such as acrylic, glass, carton, stone and wood
- Compatible with any nexmosphere Xperience controller
- Powered and programmable by nexmosphere Xperience controller
- Ultra flat (4mm), easy to integrate
- Bright white indication LED’s (custom colors on request)
- 4 programmable options for LED output; on, off, slow & fast blink
- Multiple data gathering functionalities on Xperience controller offer unique insight in how your application is being used
- One medium size capacitive touch buttons (20mm)
- One bright controllable LED
- SKU:45214
- GTIN/EAN:8720064452141
- MPN:XT-1GW6
Nexmosphere X-Touch, 1 large button, Rectangular, White LED, 180cm cable. Type: LED module, Product colour: White, Operating temperature (T-T): 10 - 40 °C. Power consumption: 10 mA. Weight: 35 g, Length: 74.5 mm, Width: 50 mm
The X-Touch 1E is a rectangular shaped board with one small size capacitive touch button
The X-Touch board can easily be connected to any of the Nexmosphere Xperience controllers using the X-talk interface. All settings of the X-Touch board are programmable on the Xperience controller, enabling a seamless integration in your application.
Warranty: 1-year
Type
LED module
Country of origin
China
Operating temperature (T-T)
10 - 40 °C
Product colour
White
Power consumption
10 mA
Length
74.5 mm
Width
50 mm
Height
3.4 mm
Weight
35 g
Sustainability certificates
CE, RoHS
Sustainability compliance
Yes
Warranty period
1 year(s)
Customs product code (TARIC)
8536501990
