Nexmosphere XL-Snapper, Pick-up & Security, curved cover, 180cm cable, black

Nexmosphere XL-Snapper, Pick-up & Security, curved cover, 180cm cable, black

XL-Snapper, Pick-up & Security, curved cover, 180cm cable, black

  • Magnetic pick-up detection sensor
  • Active product security
  • Auto-calibration
  • 4 strong neodymium magnets ensure that the product always returns to its original position
  • Securely mounts on any flat surface, horizontal, vertical, or angled
  • Light and flexible cable allows customers to experience the real weight and feel of the merchandise
  • Easy removable non-marking double-sided tape
  • Status LED for visual feedback
  • Available with flat or curved cover
  • SKU:44631
  • GTIN/EAN:8720064446317
  • MPN:XLCB-X36

You need to login to view the price.

Add To Favorite
View full details

The XL-Snapper detects either release from, or connection with, -its passive counter block and sends triggers to the connected Xperience controller accordingly, both registering pick-ups and place downs. Use the flat XL-Snapper for presenting larger devices like tablets and the curved model for rounded devices such as hair stylers.

Pickup detection
The sensor registers release from, or connection with, -its passive counter block. Both events will be sent as triggers from the Xperience controller to the connected media player, for example, to start a video or illuminate a string of LEDs.

Security
The alarm gets triggered if the merchandise is removed; cables are cut or removed from the Xperience controller. The micro-optical sensor has no moving parts eliminating false alarms caused by commonly used micro switches.

X-talk
The XL-Snapper can easily be connected to any of the Nexmosphere Xperience controllers using the X-talk interface. All settings of the sensor are programmable on the controller, enabling a seamless integration in your application.

Technical details
Compliance certificates
CE, RoHS
Sustainability compliance
Yes
Dimensions (WxDxH)
690 x 270 x 137 mm
Operating temperature (T-T)
10 - 40 °C
Storage temperature (T-T)
-20 - 50 °C
Weight
55.5 g
Sustainability certificates
CE, RoHS
Logistics data
Country of origin
Netherlands
Customs product code (TARIC)
8536501990
